DH IPC EW5541 AS TRANTECH 1

Dahua 5MP WizMind IR Fisheye Network CAMERA

IPC-EW5541-AS

Dahua 5MP WizMind IR Fisheye Network CAMERA with fisheye lens, Dahua Fisheye series camera can realize 360° surveillance, and it is widely applied in various scenes such as airports, shopping centers, banks and hotels.

Features:

  • 5MP, 1/2.7” CMOS image sensor, low illuminance, high image definition
  • Outputs max. 5MP (2592 × 1944) @25/30 fps
  • H.265 codec, high compression rate, ultra-low bit rate
  • Built-in efficient IR illuminator, and the max. illumination distance: 10 m
  • ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
  • 120dB WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
  • Intelligent detection: Intrusion, tripwire, people counting in area
  • Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection
  • Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card, built-in Mic
  • 12V DC/PoE power supply, easy for installation
  • Heat map for people counting. You can adjust the number of people, time threshold to generate a heat map, which can be exported.
Login for pricing
SKU: 85242 Categories: , Tag:

Camera
Image Sensor 1/2.7″ 5Megapixel progressive CMOS
Max. Resolution 2592 (H) × 1944 (V)
ROM 128 MB
RAM 512 MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
Min. Illumination 0.006 Lux@F2.0 (Color, 30IRE)

0.0006 Lux@F2.0 (B/W, 30IRE)

0 Lux (Illuminator on)
S/N Ratio > 56 dB
Illumination Distance 10 m (32.8 ft)
Illuminator On/Off Control Auto/Manual
Illuminator Number 3 (IR LED)
Lens
Lens Type Fixed-focal
Mount Type M12
Focal Length 1.4 mm
Max. Aperture F2.0
Field of View Horizontal: 180°
Vertical: 180°
Diagonal: 180°
Iris Type Fixed
Close Focus Distance 0.2 m (0.7 ft)
DORI Distance Detect Observe Recognize Identify
28 m

(91.9 ft)

 11.2 m

(36.7 ft)

 5.6 m

(18.4 ft)

 2.8 m

(9.2 ft)
Smart Event
Heat Map Yes
Professional, intelligent
IVS (Perimeter Protection) Tripwire; intrusion
People Counting Support people counting in area, and displaying and outputting yearly/monthly/daily reports (matching devices are needed); support people counting in 4 areas
Intelligent Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
Video
Video Compression H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Smart Codec Smart H.265+/ Smart H.264+
Video Frame Rate Main stream (2592 × 1944 @1–25/30 fps)
sub stream (704 × 576 @1–25 fps/704 × 480 @1–30 fps)
third stream (1280 × 720 @1–25/30 fps)
Stream Capability 3 streams
Resolution 5M (2592 × 1944); 3M (2048 × 1536); UXGA (1600 × 1200); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control CBR/VBR
Video Bit Rate H.264: 3 kbps–8192 kbps
H.265: 3 kbps–8192 kbps
Day/Night Auto (ICR)/Color/B/W
BLC Yes
HLC Yes
WDR 120 dB
Scene Self-adaptation (SSA) Yes
White Balance Auto/natural/street lamp/outdoor/manual/regional custom
Gain Control Auto/Manual
Noise Reduction 3D DNR
Motion Detection OFF/ON (4 areas)
Region of Interest (RoI) Yes (4 areas)
Smart Illumination Yes
Privacy Masking 4 areas
Audio
Built-in MIC Yes
Audio Compression PCM; G.711a; G.711Mu; G726
Alarm
Alarm Event No SD card; SD card full; SD card error; service life warning (supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; people counting in area; stay alarm; people counting; people No. exception detection; safety exception
Network
SDK and API Yes
Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP
Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Interoperability ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P
User/Host 20 (Total bandwidth: 64 M)
Storage FTP; SFTP; Micro SD card (support max. 256 G); NAS
Browser IE: IE8, IE9 and IE11
Chrome
Firefox
Management Software Smart PSS; DSS; DMSS
Mobile Phone IOS; Android
Certification
Certification CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
Port
Audio Input 1 channel (RCA port)
Audio Output 1 channel (RCA port)
Alarm Input 1 channel in: 5mA 3V–5V DC
Alarm Output 1 channel out: 300mA 12V DC
Power
Power Supply 12V DC/PoE
Power Consumption Basic power consumption: 3.6W (12V DC); 4.4W (PoE)
Max. power consumption (H.265 + IR on+ intelligent function + WDR): 7.3W (12V DC); 8.8W (PoE)
Environment
Operating Conditions –10°C to +50°C (14°F to +122°F)/Less than 95% RH
Strorage Conditions –40°C to +60°C (–40°F to +140°F)
Structure
Casing Metal + plastic
Dimensions 44.6 mm × Φ126.2 mm (1.8″ × Φ5.0″)
Net Weight 299 g (0.7 lb)
Gross Weight 441 g (1.0 lb)

Brand

Dahua

Datasheet

Download

DH-IPC-EW5541-AS_TRANTECH
